GM 4 All-wheel drive – sports field drainage with the trencher

GM4 4WD trencher for sports field drainage

The GM4 4WD trencher from Lingener Baumaschinen is a powerful machine designed for sports field drainage. The machine has a powerful 4-cylinder diesel engine and hydrostatic drive system that provides high performance and mobility.

The GM4 4WD is equipped with a special milling system that enables precise and uniform trenching for sports field drainage. The machine is able to cut trenches up to 60 cm deep and 30 cm wide to effectively drain water and keep the site dry.

The machine is also equipped with a special protection system that prevents the milling head from penetrating too deeply into the soil and damaging the drainage system underneath. This is especially important to ensure that the drainage system lasts a long time and is not damaged. This is important in sports field drainage.

The GM4 4WD has a hydraulic connection that allows to connect different attachments such as a plow, a milling wheel or a sweeper to adapt the machine for different tasks on the sports field.

In addition, the GM4 4WD is easy to operate and has a user-friendly control panel, ideal for sports field drainage, which allows quick and easy control of the machine. The machine is also easy to maintain and repair, which extends its service life and reduces operating costs.

Overall, the GM4 4WD is a robust and reliable machine designed for sports field drainage. It is easy to use, versatile and can be quickly adapted to the requirements of different projects.

Practical pictures trencher GM4 4WD in various applications.

Data sheet GM4 4WD

Milling width: 70-450 mm
Milling depth: 300-1500 mm
Engine: Doosan diesel, water cooled, 60KW/79PS
Traction drive: 4X radial piston motor infinitely variable (2 x m.
Working/ Transport speed: 0-12 km/h
Milling chain drive: mech/hyd. via. Power belt
Steering: hydr. via steering wheel
Electrical system: 12V
Hydraulic system: Tandem control pump Rexroth -Control panel -additional hydr. via gear pump
Tire undercarriage crawler: 31x15.5-12 Terra/Farmer
Standard equipment: - Standard conveyor belt hydr.
- sole scraper
- Trench edge scraper
- All-wheel drive (stepless)
- Vertical adjustment hydr. 15 deg.
Milling beam depth: 600, 850, 1250, 1500 mm optional 3000 mm
Chain width: 70, 150, 200, 250, 300 ,350, 400 and 450 mm
Weight: 4400 KG
Length: 5800 mm
Width: 1900 mm
Height: 2700 mm
Advantages of the GM4 4WD trencher for sports field drainage

The GM4 4WD trencher offers a number of advantages for sports field drainage:

Efficiency: GM4 4WD trencher is a powerful machine that can excavate a large amount of soil in a short time and drain the subsoil effectively. This results in faster sports field drainage and a quicker return to use.

  • Precision: GM4 4WD trencher has precise control and a wide range of settings that allow to cut the trench with high accuracy and according to the requirements of the sports field. This results in better sports field drainage and an overall higher standard of quality.
  • Versatility: The GM4 4WD is a versatile machine, able to work in different types of soil and operate in different terrain conditions. This allows flexible adaptation to the respective requirements of the sports field.
  • Time and cost saving: GM4 4WD trencher can dig a large amount of soil in a short time and improve drainage effectively. This results in a reduction in labor time and therefore labor costs compared to other manual methods for sports field drainage.
  • Minimal damage to the sports field: The GM4 4WD trencher causes minimal damage to the sports field compared to manual methods such as digging by hand or using machines with large buckets. This minimizes the need for additional repair work and minimizes disruption to game operations.

Overall, the GM4 4WD trencher is an effective and versatile sports field drainage solution that minimizes time, cost and disruption to game operations while improving sports field drainage.

To get a better insight into the performance and capabilities of the trencher working speed, we recommend you to watch our videos on https://lingener-baumaschinen.de/videos/. There you will find informative content and hands-on demonstrations that will show you how this machine can revolutionize your construction project. In addition to this, we invite you to visit our video channel on YouTube. There you will find more videos that provide detailed insights into the functions and use of the trencher working speed.
